REHD-D07-063
REHD-D07-063
Regular price
¥0.00 CNY
Regular price
Sale price
¥0.00 CNY
Unit price
/
per
Taxes included.
Tax included. Shipping calculated at checkout.
SKU:
Out of stock
Couldn't load pickup availability
Technical Specifications：
| Description | Data |
| Working Environment | -40 °C to 80 °C, 20% to 97% relative humidity (RH) |
| Lock Core's Resistance to Torsion | 12 Nm |
| Service Life | Over 200,000 operations |
| Data Retention | Over 10 years |
| Electrostatic Protection (Contact) | 8 KV |
| Electrostatic Protection (Air) | 15 KV |
| Over-current Protection | 500 mA |
| Blacklist | 10 |
| Event Record | 16 |
| Material | Aluminum alloy |
| Surface | Spray painting |
| Protection Level | IP68 with E-Plug Protected |
| Design Reference | DIN EN15684 |
| Electronic Key Related Security | EN 15684: 2013-01: Class F |
| Durability |
EN 15684: 2013-01 (Classes 4 - 6): E-Plug Class 6, 100,000 cycles |
