REIB-B05-001
REIB-B05-001
Regular price
¥0.00 CNY
Regular price
Sale price
¥0.00 CNY
Unit price
/
per
Taxes included.
Tax included. Shipping calculated at checkout.
SKU:
Out of stock
Couldn't load pickup availability
Technical Standards：
| Description | Data |
| Working environment | -40 °C to 80 °C, 20% to 97% relative humidity (RH) |
| Lock cylinder's resistance to torsion | 12 Nm |
| Service life | Over 200,000 operations |
| Data retention | More than 10 years |
| Electrostatic protection (contact) | 8 kV |
| Electrostatic protection (air) | 15 kV |
| Over-current protection | 500 mA |
| Blacklist | 10 |
| Event record | 16 |
| Materials | Brass |
| Dimensional Specifications | 65mm - 120mm, supporting equal and unequal spacing |
| Protection Level | IP68 with E-Plug Protected |
| Design References | DIN EN 15684 |
| Electronic Keys Related Security | EN 15684: 2013-01: Class F |
| Durability | EN 15684: 2013-01 (Classes 4 - 6)；E-Plug Class 6, 100,000 cycles |
